MS9132

——————————————————————————————————————————————————————————

MS9132 is a USB 3.0 projection screen chip, which integrates USB 3.0 device controller, data transceiver module, video and audio processing module. MS9132 can display or expand the information on PC, smartphone and tablet to larger display devices through USB 3.0 interface, and supports the HDMI video interface output.





Features


  HDMI 1.4b compatible
  Supports EDID / HPD process
  Supports DVI 1.0 mode
  Default max output resolution: 1920×1080@60Hz
  Default output 48KHz stereo
  Integrated USB 3.0 device
  Compatible with USB 2.0 device mode
  Integrated USB video and audio processing module
  Windows 10 1607 or higher
  Android 5.1 or higher
  Mac OS 10.14 or higher
  External 24MHz passive crystal oscillator
  On-chip PLL
  On-chip power on reset
  QFN-48 (7mm×7mm)
  PB-free and RoHS complain


Function Block Diagram
